●models

this manual is applied to following models:

model	yzpc-3862-j	yzpc-3862-e
cpu	j1900	e3845
com	3	3
lan	1	1
hdmi	0	0
vga	0	0
mini pci-e	2	2
lvds	dual 24-bit	dual 24-bit

●attentions

●notes under a table or figure indicate the difference of models, or alternative definition of specific pin of the header (jumper/connector).
●how to identify the first pin of a header or jumper
■usually, there is a thick line or a triangle near the header’s or jumper’s pin 1.

■square pad, which you can find on the back of the motherboard, is usually used for pin 1.

●specification

model	yzpc-3862
cpu	intel® celeron® j1900, quad core, clock speed 2ghz, tdp 10w
	intel® atom™ e3845, quad core, clock speed 1.91 ghz, tdp 10w
display	1 * dual channel 24-bit lvds
memory	support ddr3l 1333 mhz, 1 * so-dimm slot, up to 8gb
storage	1 * serial ata 2.0 port 1 * msata
ethernet	1 * realtek pci-e nic rtl8111f for 1000mbps
audio	realtek alc662 5.1 channel hda codec , support mic/line-out ports 1 * amplifier, 6-w (per channel) into an 8-ω loads
com	3* rs232
other ports	usb:1rear i/o(usb3.0/usb2.0) 3rear i/o(usb2.0) 8 * gpio 1 * ps/2 pin header 2 * mini pci-e 1 * sim card slot 1 * front audio 2 * 12vdc_in power input connector
temperature	j1900 storage: -40~110 ^oc operating: -20~85 ^oc	e3845 storage: -40°c ~ 110°c operating: -40°c ~ 85°c
bios	ami uefi bios
factor	208mm * 127mm

●jumpers/headers and connectors

jumpers / headers and connectors
power	1	12	jlv1
dc12vin1	2	13	con6
con24	3	14	lvds1
rj45_led_shell	4	15	left channel
usba-double	5	16	right channel
com1	6	17	header
com2	7	18	backlight
com3	8	19	header 2
2erjrc-35-4p	9	20	con10a
header 4	10	21	hdr254_1x2
sip7m2	11

●definition of jumpers/headers and connectors

dc12vin1

definition	pin	pin	definition
v12al	1	2	gnd

2erjrc-35-4p

2erjrc-35-4p j12

definition	pin	pin	definition
canl	1	2	canh

header 4

header 4 j5

definition	pin	pin	definition
12v	1	2	gnd
gnd	3	4	v5s

jlv1

definition	pin	pin	definition
3v3s	1	2	lcd_vcc_n
vdd5_lcd	3

con6

con6 j2

definition	pin	pin	definition
gnd	1	2	gnd
back_pwm	3	4	back_onoff
12vlcd	5	6	12vlcd

lvds1

definition	pin	pin	definition
lcd_vcc	1	2	lcd_vcc
n/c	3	4	gnd
lcd_vcc	5	6	lcd_vcc
lvds_yam0	7	8	lvds_ybm0
lvds_yap0	9	10	lvds_ybp0
gnd	11	12	gnd
lvds_yam1	13	14	lvds_ybm1
lvds_yap1	15	16	lvds_ybp1
gnd	17	18	gnd
lvds_yam2	19	20	lvds_ybm2
lvds_yap2	21	22	lvds_ybp2
gnd	23	24	gnd
lvds_clkam	25	26	lvds_clkbm
lvds_clkap	27	28	lvds_clkbp
gnd	29	30	gnd
lvds_ddcpclk	31	32	edid_data
gnd	33	34	gnd
lvds_yam3	35	36	lvds_ybm3
lvds_yap3	37	38	lvds_ybp3
v3.3s	39	40	gnd

left channel j13

definition	pin	pin	definition
outpl	1	2	outnl

right channel j14

definition	pin	pin	definition
outpr	1	2	outnr

header 36x2

header 36x2 j1

definition	pin	pin	definition
vdd5_lcd	1	2	vdd5_lcd
gnd	3	4	gnd
crt_red_cn	5	6	crt_hsync_cn
crt_blue_cn	7	8	crt_vsync_cn
crt_green_cn	9	10	crt_ddcclk_cn
gnd	11	12	crt_ddcdata_cn
conn_hdmi_sda	13	14	hdmi_hpd
conn_hdmi_scl	15	16	conn_hdmi_clkn
conn_hdmi_txn0	17	18	conn_hdmi_clkp
conn_hdmi_txp0	19	20	gnd
gnd	21	22	conn_hdmi_txn1
conn_hdmi_txn2	23	24	conn_hdmi_txp1
conn_hdmi_txp2	25	26	gnd
gnd	27	28	pcie_txp1
pcie_rxp1	29	30	pcie_txn1
pcie_rxn1	31	32	gnd
gnd	33	34	ck_100m_pcie1_n
pcie_txp3	35	36	ck_100m_pcie1_p
pcie_txn3	37	38	gnd
pcie_rxp3	39	40	ck_100m_pcie3_n
pcie_rxn3	41	42	ck_100m_pcie3_p
gnd	43	44	gnd
msin5	45	46	msin4
msout5	47	48	msout4
msout6	49	50	msin6
gpio2	51	52	sataled_n
gpio1	53	54	gpio4
suspend	55	56	sio_clk_25m
lad1	57	58	lad0
lad3	59	60	lad2
l_frame_n	61	62	ck_pch_25m_sio
fan_ctl1	63	64	lpc_clkrun_n
gnd_aud	65	66	gnd_aud
spk_out_r	67	68	mic1_r
spk_out_l	69	70	mic1_l
front-jd	71	72	mic1_jd
